Detailed setting
Press the setup button for more than 5 seconds to display the first menu of detailed settings (A-1) in the current temperature window.
Change the setting value using the down or up button.
In this way, if you finish setting up the last menu "dps" and press the last setting button, "SAU" will blink 3 times and the setting will be completed.
|
Function |
Display |
Initial value |
Range |
|
Temperature deviation |
A-1 |
2℃ |
1℃ ~ 10℃ |
|
Comp delay |
A-2 |
60 Sec. |
0 ~ 240 Sec. |
|
Comp Block |
A-3 |
0 |
0:Not used (Fixed) |
|
Defrost cycle |
A-4 |
204 Min. |
0 ~ 999 Min. |
|
Defrost time |
A-5 |
30 Min. |
0 ~ 30 MIn. |
|
EVA fan delay |
A-6 |
10 Sec. |
0 ~ 60 Sec. |
|
EVA fan function |
A-7 |
F.1 |
F.1 ~ F.4 |
|
Temperature Compensation |
A-8 |
0℃ |
-10℃ ~ 10℃ |
|
Constant temperature function |
A-9 |
0℃ |
0℃ ~ 10℃ |
|
EVA fan delay after defrost |
A-A |
0 Sec. |
0 ~ 600 Sec. |
|
Comp delay after defrost |
A-b |
0 Sec. |
0 ~ 600 Sec. |
|
Comp operation during defrost |
A-c |
OFF |
ON/OFF |
|
Temperature display after defrost |
A-d |
On |
ON/OFF |
|
Comp accumulated time |
A-E |
Off |
OFF |
|
Buzzer in case of error |
Erb |
On |
On/Off |
|
Abnormal temperature delay time |
Ert |
0 |
0: Not used 10 ~ 25 Min. |
|
Abnormal temperature high temperature deviation |
ErH |
10℃ |
1 ~ 10℃ |
|
Abnormal Temperature Low Temperature Deviation |
ErL |
-5℃ |
-1 ~ -10℃ |
|
Operation mode |
dPS |
S |
Not used/Fix |
Error message
|
Display |
Error Details |
Treatment method |
|
E-1 |
Temperature sensor disconnection |
Sensor terminal connection status Sensor resistance value check Check electric leak on sensor |
|
E-2 |
Temperature sensor short circuit |
Sensor terminal connection check Breaking off sensor wire Check electric leak on sensor |
|
Err-dp |
DPS Behavior |
DSP Behavior:High pressure switch operation DP Switch:High Pressure B Contact Behavior |
|
Err-ocr |
Comp. OCR Behavior |
Comp magnet OCR Behavior: Comp capacity, OCR(Settle) Check |
)
Factory Reset
Hold down the power button for 10 seconds and the temperature display will show "SAU". The buzzer rings and is initialized.
